When entering your ordering sizes please enter your opening width (measurement 1 on the measuring guide below) and opening height (measurement 2 on the measuring guide below).
Width - To measure the opening width, take the width measurement (1) in 3 places, across the top, middle and bottom.
If A Behind Fit: Enter the widest measurement. This should be your ordering width. The guides will fit behind the garage reveals.
If A Inbetween Fit: Enter the the shortest measurement. This should be your ordering width. The frame will fit between the opening brickwork.
Height - To measure the opening height, measure the height from the floor to the underside of the lintel in 3 places, on the left side, centre and right side.
If A Behind Fit: Enter the highest measurement. This should be your ordering height. The top box will fit behind the lintel.
If A Inbetween Fit: Enter the the shortest measurement. This should be your ordering height. The box will fit under the lintel and between the opening brickwork.

Choosing your fit type?
Fitting BEHIND the brickwork:
If you wish to have your door fitted behind the brickwork, then please check to make sure you have a minimum of 90mm behind each reveal (measurements 3 and 4 on the guide above). Along with a minimum of 300mm available behind the lintel (measurement 5 on the guide below).
The minimum side room required for a behind-fit is 90mm behind each reveal. (this allows for the guides)
The minimum headroom required for a behind-fit is 300mm behind the lintel. (this allows for the top box that the door rolls up into.)
Fitting INBETWEEN the brickwork:
If you wish to have your door fitted between the brickwork, we will deduct the guide and box for you, so please enter the opening sizes. (Measurements 1 and 2 on the guide above)
We always suggest allowing a 10mm tolerance on both the height and width for inbetween fits. For example, if your opening width is 2400 mm, then you should place the order as 2390 mm.
